50G AWG Mux

Ask Lasest Price
Brand Name :	Seacent
Model Number :	40-CH 100G
Certification :	ISO9001,ROHS
Price :	negotiation
Payment Terms :	L/C, T/T
Supply Ability :	100,000 per month
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

50G AWG Mux

40 CH 50G Thermal AWG Mux Low Insertion Loss in DWDM system

AWG MUX Description

Seacent Photonics offers a full range of Thermal/Athermal AWG products, including 50GHz, 100GHz and 200GHz Thermal/Athermal AWG.Here we present the generic specification for the 40-channel 100GHz Flat Top Thermal AWG (40 channel TAWG) MUX/DEMUX component supplied for use in DWDM system.

AWG MUX Features

Low insertion loss
High return loss
High isolation
compact desigh
Thermal stability
Telcordia GR-1221-CORE qualified

AWG MUX Application Areas

CATV
FTTH
LAN
DWDM systems
network monitoring
real-time line monitoring system

AWG MUX Parameters

Parameter	Unit	Flat top	Gaussion	Flat top	Gaussion
Number of channels		16/32/40/48		80/88/96
Channel spacing	Ghz	50		50
Channel frequency	Thz	Blue band=1528.773~1547.316 Red band=1545.720~1564.679		C-band=1526.827~1564.679
Wavelength accuracy	nm	±0.05	±0.05	±0.05	±0.05
1db bandwidth	nm	≥0.18	≥0.12	≥0.18	≥0.12
3db bandwidth	nm	≥0.28	≥0.20	≥0.28	≥0.20
Insertion loss(passband)	dB	≤4.5	≤3.7	≤5.5	≤4.5
Adjacent channel crosstalk	dB	≥27		≥27
Non-adjacent channel crosstalk	dB	≥30		≥30
Total crosstalk	dB	≥24		≥24
Insertion loss uniformity	dB	≤1.2		≤1.5
Polarization loss	dB	≤0.5	≤0.5	≤0.5	≤0.5
Return loss	dB	≥40
Dispersion	ps/nm	±10
Operating temperature	℃	-20~70
Size(lengthwidthheight)	mm	1207012.3		1309011.3

DWDM-AWG-Seacent Photonics.pdf
